Mobile drying fan

Mobile drying fans are suitable for temporary ventilation tasks, drying and aeration.

DANHEAT’s mobile drying fans provide a fast and flexible solution to tasks where periodic ventilation is required.

The fans have a very high air performance and are particularly suitable for ventilation (drying) of eg. potatoes, carrots and other root crops, as well as cooling a possible. chocolate stock.

The fans are also suitable for stall cleaning, where ventilation of a building must be quickly established.

The fan socket is made of rolled steel plate with welded motor console for optimum strength.

The fan unit is mounted in a solid steel frame. The entire unit is ground and lacquered with black polyester lacquer.

The device is provided with a plastic wrap in fiberglass reinforced material. The wing is dynamically balanced and is resistant to most aggressive gases.

All models are fitted with protective gratings on the inlet and outlet.

Connection is via external terminal box, encased IP65, equipped with 2-pole switch.

All engines are encapsulated IP65, Insulation class F and fitted with thermal protection.

All engines, except engines for size 630, are suitable for stepless regulation.

The air direction is standard wing motor.

Also available in 3×230 / 400 V.

Air temperatures from -400C to + 700C.
